Zirconium Foil
Custom zirconium foil and strip for demanding chemical service, reliable quality, and responsive global supply.
Zirconium foil is used where corrosion resistance in demanding chemical environments is a central requirement. Supply is reviewed by grade, thickness, width, surface, condition, and inspection documentation.
Sourcing data for zirconium foil.
| Typical forms | Foil, strip, sheet, cut piece |
|---|---|
| Thickness range | 0.02-1.0 mm |
| Width range | Up to 680 mm by project review |
| Common grades | Zr702, Zr705, UNS R60702, UNS R60705 |
| Reference standards | ASTM B551 / project specification |
| Condition | Annealed or project-defined condition |
Select the grade for the service conditions.
Use these as selection starting points. Final choice depends on the drawing, governing specification, service conditions, and qualification requirements.
| Grade | Typical selection logic | Confirm before quotation |
|---|---|---|
| Zr 702 / UNS R60702 | Commercial zirconium grade used for corrosion-resistant chemical-process equipment and components. | Process media, concentration, temperature, product form, fabrication route, and specification. |
| Zr 705 / UNS R60705 | Niobium-alloyed zirconium considered when higher strength is required for a defined service. | Strength requirement, corrosion basis, welding or forming route, heat treatment, and specification. |
Three items to prevent specification gaps.
Confirm dimensions together with grade, condition, tolerances, quantity, and inspection scope.
Thickness, width, and tolerance
State finished thickness, width, coil or cut length, quantity, dimensional tolerances, and any flatness, camber, or edge requirements.
Condition and surface
Specify annealed or cold-worked condition, surface finish, cleanliness, edge condition, and restrictions related to forming, welding, or appearance.
Coil format and documents
Define coil weight, inner diameter, slitting, protective packing, governing standard, certificate type, traceability, and testing scope.
Match foil & strip supply to the application.
End use determines the grade, condition, dimensional control, surface preparation, testing, traceability, and downstream fabrication route.
Chemical processing
Material selection requires the actual process media, concentration, temperature, pressure, impurities, fabrication route, and corrosion-design basis.
Review application detailsHigh-purity process equipment
Define cleanliness, surface condition, dimensional control, joining route, traceability, and contamination-sensitive handling requirements.
Review application detailsMarine and severe corrosion service
Suitability depends on the complete environment, temperature, stresses, crevice conditions, fabrication details, and applicable project specification.
Review application detailsSpecialty engineered components
Provide the drawing, load case, service environment, product standard, qualification plan, and required records before finalizing the supply route.
Review application detailsDefine inspection and documentation before production.
Align document requirements with the production lot, inspection plan, marking, and final records.
- Material identity and heat or lot traceability aligned with the delivered coils, strips, or cut pieces when required
- Chemical and mechanical results checked against the specified product standard when required
- Thickness, width, length, edge, surface, camber, and coil-format checks agreed for the order
- Certificate type, additional testing, marking, coil protection, and packing confirmed before order release
Frequently asked questions about zirconium foil.
Which zirconium grades are available as foil?
Zr702, Zr705, UNS R60702, and UNS R60705, rolled to ASTM B551 or project specification.
What size zirconium foil can you supply?
0.02 to 1.0 mm thick, up to 680 mm wide by project review, with precision rolling, slitting, and annealing.
Is zirconium foil suitable for hydrochloric acid service?
Yes. Zirconium offers excellent resistance to hydrochloric acid and chloride-bearing media, so it is specified for aggressive chemical environments.
Custom processing around the drawing.
Send target dimensions, tolerances, surface, package format, and inspection requirements so the production route can be reviewed before quotation.
Send enough detail for a technical review.
Mark unknown items for discussion. This separates confirmed requirements from points requiring engineering or procurement review.
- Grade or alloy designation
- Governing standard and revision
- Thickness, width, coil or cut length, and tolerances
- Condition, surface, edge, flatness, and camber requirements
- Quantity, coil weight, inner diameter, and acceptable production unit
- Slitting, cutting, forming, or drawing requirements
- Inspection, testing, certificate, and traceability scope
- Packing, marking, destination, and requested delivery window
Related material pages.
Use these links to compare adjacent product forms and materials without returning to the full product directory.
Send a zirconium foil requirement.
Include grade, standard, dimensions, tolerance, condition, surface, quantity, destination, and required documents. A drawing or previous specification helps us respond faster.
